DIELECTRIC
介質
|
Polyester film
聚酯薄膜
|
|
ELECTRODES
電極
|
Vacuum evaporated metal
真空蒸鍍金屬
|
|
COATING
包封
|
Encapsulated in reinforced flame retardant plastic case sealed with epoxy resin meeting the requirement of UL 94V-0，
UL94V-0盒子并用環(huán)氧樹脂封裝
|
|
LEADS
導線
|
Radial leads of tinned wire
徑向鍍錫導線
|
|
REFERENCE STANDARD
引用標準
|
IEC 384-2 grade 1；SJ/T 10874-1996
|
|
CLIMATIC CATALOGUE
氣候類別
|
40/100/21 (From 85℃ up to 105℃ with derating voltage 1.25%/℃)
(85℃至105℃間按1.25%/℃遞減電壓 )
|
|
CAPACITANCE VERSUS
RATED VOLTAGE(UR)
靜電容量與額定電壓
|
0.001μF-6.8μF50/100VDC 0.001uF-6.8uF/250VDC
0.001μF-2.2μF/400VDC 0.001μF-1.5μF/630VDC
|
|
CAPACITANCE TOLERANCE
靜電容量誤差
|
M=±20% K=±10% J=±5%
|
|
DISSIPATION FACTOR
（TANGENT OF LOSS）
散逸因素（損耗角正切）
|
C≤1.0uF DF≤0.8%; C＞1.0uF DF≤1.0%
（at 20℃,1KHz）
|
|
VOLTAGE PROOF
耐電壓
|
1.6*UR Unit:VDC (5s at 20℃)
|
|
INSULATION RESISTANCE
絕緣電阻
|
C≤0.33uF, IR≥15000MΩ; C＞0.33uF, IR*C≥3000S
（1minute at 20℃ and RH≤65%）
|
|
ENDURANCE
耐久性
|
1000 hours with 125% of rated voltage at 85℃,After the Test
85℃條件下，125%之額定電壓1000小時。試驗完成后：
△C/C≤8%；△DF≤0.30%（C＞1μF）；
△DF≤0.50%（C≤1μF）
IR≥0.5% of the specified value （標稱值） （20℃ 1KHz）
|
