★ FEATURE

特點：

Small size

體積小

Low loss and good stability

損耗小，穩定性好

Long life due to excellent self-healing

自愈性好，壽命長

★APPLICATION

用途：

Widely used in couping,filter,noise-suppression bypass of DC and pulse circuits in all kinds of

machines

適用于投資類和消費領域整機的耦合、 濾波、降噪、旁路等直流和脈沖電路等

    DIELECTRIC

介質

Polyester film

聚酯薄膜

   ELECTRODES

電極

Vacuum evaporated metal

真空蒸鍍金屬

  COATING

包封

Encapsulated in reinforced flame retardant plastic case sealed with epoxy resin meeting the requirement of UL 94V-0，

UL94V-0盒子并用環氧樹脂封裝

  LEADS

導線

Radial leads of tinned wire

徑向鍍錫導線

REFERENCE STANDARD

引用標準

GB7322；IEC60384—2

CLIMATIC CATALOGUE

氣候類別

40/85/21  (From 85℃ up to 105℃ with derating voltage 1.25%/℃)

          (85℃至105℃間按1.25%/℃遞減電壓)

   CAPACITANCE VERSUS

    RATED VOLTAGE(U_R)

     靜電容量與額定電壓

0.0010μF-1.0μF/50VDC、63VDC

0.0010μF-0.68μF/100VDC

0.0010μF-0.15μF/250VDC

 CAPACITANCE TOLERANCE

 靜電容量誤差

M=±20%  K=±10%  J=±5%

    DISSIPATION FACTOR

  （TANGENT OF LOSS）

   散逸因素（損耗角正切）

≤1.0%  （at 20℃,1KHz）

  VOLTAGE PROOF

耐電壓

1.6*UR   Unit:VDC   (5s at 20℃)

  INSULATION RESISTANCE

絕緣電阻

C≤0.33μF, IR≥5000MΩ; C＞0.33μF, IR*C≥3000S

UR≤100V   Testing by 50 V;     UR＞100V   Testing  by 100 V

（1minute at 20℃ and RH≤65%）

 ENDURANCE

 耐久性

1000 hours with 125% of rated voltage at 85℃.After the test:

85℃條件下，125%之額定電壓1000小時。試驗完成后：

 △C/C≤5%；△DF≤0.20%

C≤0.1μF，IR≥9000MΩ C＞1μF

 IR≥50% of the specified value （標稱值）.  （20℃ 1KHz）

capacitance

50/63VDC

100VDC

250VDC

symbol

uF

W

H

T

P

dφ

W

H

T

P

dφ

W

H

T

P

dφ

102

0.0010

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

122

0.0012

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

152

0.0015

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

182

0.0018

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

222

0.0022

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

272

0.0027

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

 332

0.0033

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

392

0.0039

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

472

0.0047

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

562

0.0056

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

682

0.0068

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

822

0.0082

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

103

0.010

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

123

0.012

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

153

0.015

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

183

0.018

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

223

0.022

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

7.5

3.5

5.0

0.5

273

0.027

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

7.5

3.5

5.0

0.5

333

0.033

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

7.5

3.5

5.0

0.5

393

0.039

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

7.5

3.5

5.0

0.5

473

0.047

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

9.5

4.5

5.0

0.6

563

0.056

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

9.5

4.5

5.0

0.6

683

0.068

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

9.5

4.5

5.0

0.6

823

0.082

7.2

6.5

2.5

5.0

0.5

7.2

6.5

2.5

5.0

0.5

7.2

10.0

5.0

5.0

0.6

104

0.10

7.2

6.5

2.5

5.0

0.5

7.2

7.5

3.5

5.0

0.5

7.2

10.0

5.0

5.0

0.6

124

0.12

7.2

6.5

2.5

5.0

0.5

7.2

9.5

4.5

5.0

0.6

7.2

11.0

6.0

5.0

0.6

154

0.15

7.2

7.5

3.5

5.0

0.5

7.2

9.5

4.5

5.0

0.6

7.2

11.0

6.0

5.0

0.6

184

0.18

7.2

7.5

3.5

5.0

0.5

7.2

9.5

4.5

5.0

0.6

224

0.22

7.2

7.5

3.5

5.0

0.5

7.2

10.0

5.0

5.0

0.6

274

0.27

7.2

9.5

4.5

5.0

0.6

7.2

10.0

5.0

5.0

0.6

334

0.33

7.2

9.5

4.5

5.0

0.6

7.2

11.0

6.0

5.0

0.6

394

0.39

7.2

9.5

4.5

5.0

0.6

7.2

11.0

6.0

5.0

0.6

474

0.47

7.2

10.0

5.0

5.0

0.6

7.2

11.0

6.0

5.0

0.6

564

0.56

7.2

10.0

5.0

5.0

0.6

7.2

11.0

6.0

5.0

0.6

684

0.68

7.2

11.0

6.0

5.0

0.6

7.2

11.0

6.0

5.0

0.6

824

0.82

7.2

11.0

6.0

5.0

0.6

105

1.0

7.2

11.0

6.0

5.0

0.6
